VSP2K
TERMINAL SIGNAL DECODER
Support 4G, WiFi, wired network and other networking methods, rapid deployment to realize intelligent cloud management function, multi-screen, multi-service, cross-regional unified management. It supports the use of PE for program editing and information release, supports the arbitrary arrangement of multiple windows of programs, and supports the playback of various program materials such as videos, pictures, texts, tables, weather, and clocks. It is widely used in the field of LCD commercial display, such as chain store screens, advertising machines, retail store screens, screens that do not require a PC, etc.
Features
• Support 1080P HD output
• Support horizontal and vertical screen switching
• Support horizontal and vertical screen switching
• WIFI, wired Ethernet port, U disk, 4G (optional) multiple communication methods
• Built-in 8GB (5G available for users), supports U disk expansion
• Built-in 8GB (5G available for users), supports U disk expansion
• 3.5mm audio output, audio and video synchronization output
• Window and Material Playback
– Support multiple windows and multiple materials to play on the screen at the same time
– Support rich media materials, such as pictures, videos, texts, clocks, etc., support
– Up to 1 1080P or 3 720P video playback
– Support multiple windows and multiple materials to play on the screen at the same time
– Support rich media materials, such as pictures, videos, texts, clocks, etc., support
– Up to 1 1080P or 3 720P video playback
• Control method
– Support Kares cloud platform, hierarchical management and multi-role program release
– All-new Kommander PE program editing, drag and drop operation, do what you want
– The simple APP allows you to fully control screen adjustment, editing, and management, and play with the big screen at your fingertips.
– Support Kares cloud platform, hierarchical management and multi-role program release
– All-new Kommander PE program editing, drag and drop operation, do what you want
– The simple APP allows you to fully control screen adjustment, editing, and management, and play with the big screen at your fingertips.
Download VSP2K Brochure
Specs
| Model | |||
| INTERFACE TYPE INPUT | |||
| USB2.0 | 2x USB2.0 storage expansion is possible (U disk or SD card,up to 128G) | ||
| RJ45 | 1x 100M input network port Access to LAN,cluster control | ||
| RS232C | 1x RS232C interface,can be controlled by external sensor | ||
| IR | 1x IR | ||
| WIFI | WiFiAP+STA dual WiFi mode,can be used as a hotspot for mobile phones and computers to connect | ||
| 4G(Optional) | Access to WAN | ||
| DC power input | DC 5V/2A power supply | ||
| INTERFACE TYPE OUTPUT | |||
| HDMI out | 1x HDMI out | ||
| RS232C | 1x RS232C | ||
| PERFORMANCE PARAMETERS | |||
| Hardware Performance | 1.6GH,quad-core CPU,3D GPU 1GB@600MHz DDR3 high-speed RAM Support 1080p@60fps hard decoding playback Support 1080p@30fps hardware encoding | ||
| Storage | Built-in 8GB storage (users can use 5G) | ||
| OS | Android | ||
| Load | 1080P output | ||
| Wifi connection distance | 20米(no occlusion) | ||
| SUPPORTS MULTIMEDIA FORMATS | |||
| Net weight | 9Kg | ||
| Video format | AVI,WMV,MPG,RM/RMVB,VOB,MP4,FLV and other common video formats; Support multi-video playback at the same time | ||
| Audio format | MPEG-1 LayerⅢ,AAC etc. | ||
| Image format | Support bmp、jpg、png etc | ||
| Text | Single-line text,static text,multi-line scrolling text,office,etc. | ||
| Clock | Real-time clock,multi-regional clock display and management | ||
| MACHINE SPECIFICATION | |||
| Dimensions | 151×100×28mm(L×W×H) | ||
| Input Adapter Power | DC 12V/1A power supply | ||
| rated power | 10W | ||
| Operating temperature | -20℃-80℃ | ||
| Working humidity(%) | 5%-95% | ||
| Dimensions | 151x100x28mm(L×W×H) | ||
